Mechanical

Dimensions

139.7 x 96 x 31.2 mm (5.5 x 3.8 x 1.3")

Weight

460 g (1 lb)

Enclosure Material

Plastic, aluminum

Mount Material

Aluminum

Hardware

Networking Interface

Data-in: (1) GbE RJ45 port
Data-out: (4) GbE RJ45 ports

Management Interface

Ethernet, Bluetooth

PoE Interface

PoE in: (1) PoE in (PoE output not used)
PoE out: (1) Requires PoE+ switch

Power Method

PoE, PoE+ (Required for PoE output)

Power Supply

UniFi PoE switch, 48V 0.5A PoE adapter (Optional)

Max. Power Consumption

13W (Excluding PoE output)

Max PoE Wattage (per Port)

15.4W*
*Requires a PoE+ switch

Voltage Range (PoE Mode)

44–57V DC

Max. TX Power

2.4 GHz: 22 dBm
5 GHz: 26 dBm
6 GHz: –

MIMO

2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
5 GHz: 4 x 4 (DL/UL MU-MIMO)
6 GHz: –

Max. Data Rate

2.4 GHz: 573.5 Mbps (BW40)
5 GHz: 4.8 Gbps (BW160)
6 GHz: –

Antenna Gain

2.4 GHz: 5 dBi
5 GHz: 5.9 dBi
6 GHz: –

LED

White/blue

Button

Factory reset

Mounting

Wall (Included)

Ambient Operating Temp

-30 to 60°C (-22 to 140°F)

Ambient Humidity

5 to 95% noncondensing

Certifications

CE, FCC, IC

Software

WiFi Standards

802.11a/b/g/n/ac/ax (WiFi 6)

Wireless Security

WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

BSSID

8 per radio

VLAN

802.1Q

Advanced QoS

Per-user rate limiting

Guest Traffic Isolation

Supported

Concurrent Clients

300+

Zero-wait DFS

Yes*
*Supported with upcoming firmware versions

Supported Data Rates

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac: 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6): 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

Application Requirements

UniFi Network: Version 6.4.52 and later
