Dimensions

Height

164 mm

Width

910 mm

Depth

130.5 mm

Lens Depth

28.8 mm

Weight

7.08 kg

Technical Specifications

Certifications & Compatibility

Visit Logitech Certifications for latest info

Teams Compatibility

Microsoft Teams Rooms on Android and Windows (for medium-sized rooms)

General Specifications

Built-in Components

6 beamforming microphones, PTZ camera, 2 speakers, AI Viewfinder, table stand, cable management system

Enclosure

All-in-one with integrated table stand and patented speaker suspension

Device Management

Logitech Sync

Displays Supported

2

Display Resolution

Up to 1080p

Network Protocol

IPv4, IPv6

Proxy Support

IP, FQDN, PAC file

Camera

Resolution

4K, 1440p, 1080p, 900p, 720p, and SD (30fps)

Pan & Tilt

Motorized Pan: ±25°, Tilt: ±15°

Zoom

15X HD zoom (5X optical + 3X digital)

Field of View

Diagonal: 90°, Horizontal: 82.1°, Vertical: 52.2°

Room Coverage

132.1° Horizontal x 82.2° Vertical

Speakers

Drivers

2x 70 mm

Sensitivity

92dB SPL @1W, 99dB SPL @8.0W

Power

8W

THD

1kHz < 2% at 1W

Sampling Rate

48 kHz

Impedance

4 Ohms

Microphones

Frequency Response

90Hz – 16kHz

Sensitivity

>-36dBFS ±1 dB @ 1Pa

Data Rate Output

48 kHz

Pickup Range

Up to 7 m

Beamforming Elements

6 omnidirectional MEMS microphones forming 5 adaptive beams

Audio Processing

AEC, VAD, AI-based noise suppression

Add-on Mics

Supports up to 4 Rally Mic Pods and 2 Rally Mic Pod Hubs

RightSense™ Technologies

RightLight

Natural skin tones with WDR

RightSight

Auto-framing for active speaker and AI viewfinder for all participants

RightSound

Auto-level voices and suppress background noise and echo

Grid View

Frames all participants for equitable hybrid meetings

Interfaces

HDMI

2 HDMI Out (up to 1080p), 1 HDMI In

USB

3x Type A, 1x Type C

Network

10/100/1G Ethernet

WiFi

802.11a/b/g/n/ac

External Mic Input

Yes (proprietary for Rally Mic Pod, Hub, Extension Cable)

Remote Control

Bluetooth Low Energy

Power & Cables

Power Supply

Auto-sensing (100-240V, 19V, 4.74A)

Power Supply Dimensions

127 mm x 51 mm x 30 mm

DC Cable

1.5 m

AC Cable

1 m

HDMI 1.4 Cable

2 m

USB A to C Cable

2.2 m

Environmental

Operating Temperature

0 to 40°C

Storage Temperature

-40 to 70°C

Humidity

10 to 95%

BTU/hr

57 (idle), 64 (in meeting)

Security

Full Disk Encryption

AES-128

Data Encryption

Symmetric Keys, PKI

Device Access

Authenticated using API

Key Protection

Arm TrustZone, RPMP

Accessories

Mounts

Wall Mount, TV Mount for Video Bars

Audio

Rally Mic Pod, Rally Mic Pod Hub, Rally Mic Pod Mount

Connectivity

Logitech Strong USB (10m, 25m, 45m)

Touch Controller

Logitech Tap, Tap IP

Part Numbers

Graphite: 960-001308; White: 960-001320

Compatibility

Internet Connection

Wired or Wireless

USB Mode

Windows 10, 11; macOS (two most recent versions)

Appliance Mode

Requires room solution software license
